Solar collector Compact

  • High quality, long-lasting LDPE collectors
  • Can be extended indefinitely
  • Ready to assemble
  • The solar collector is suitable for salt water

Sold Out

The selected product is currently not available. As soon as the product is on stock, we will send you an E-mail.

Notifiy me:

As low as €139.00
including VAT

Solar collector Compact will keep your swimming pool warm and comfortable. Depending on the desired temperature, one or more elements can be connected in series. The connection is made between the filter pump and the basin inlet nozzle. The solar collector is suitable for salt water. Delivery is without connecting hoses or mounting material.

  • For pools up to 12.000 l capacity
  • High quality LDPE plastic
  • Hose connector Ø 32/38 mm
  • The solar collector is suitable for salt water
  • Ready to use collector for simple fitting

For optimal regulation of the water temperature we recommend our bypass set.

Hose clamp Ø 30 - 50 mm
Required quantity for your set: 4
Schlauchanschluss Ø 32/38 mm, 90 °, L-Schlitzung
Required quantity for your set: 1
O-Ring Ø 38 mm
Required quantity for your set: 6
Endkappe mit L-Schlitzung
Required quantity for your set: 1
Verschlussstopfen mit Fräsung f. O-Ring
Required quantity for your set: 1
Durchfluss Reduzierungsscheibe
Required quantity for your set: 1
FAQs from category Solar:

May I mount the solar collectors or solar mats on the roof?

In general: For every 1 m difference in height (installation height top edge solar system / filter system) the pressure in the filter tank increases by 0.1 bar. This additional pressure not only reduces the performance of the filter pump, but can also damage the vessel in extreme cases. If you have a performance diagram for the filter pump (only for sand filter systems) check the effect of the additional pressure. The main question is not whether the vessel will burst, but whether there is still sufficient circulation with the existing filter system. For sand filter systems, we recommend a maximum height difference of 2 m. For cartridge filter systems, we recommend that you start with 1 piece of solar collector and slowly expand. Attention! A cartridge filter system does not have the same pump pressure as a sand filter system. In many cases, it already stops with one collector connected. These filter systems are not designed to pump upwards. Place the collector directly next to the filter system on the ground.

The solar mats/collectors do not suck up water, what can I do?

The solar mats must be connected after the filter system and then the filter system must be switched on.

The solar mats/collectors do not work at night, what can I do?

The solar mats and solar collectors only function with solar radiation, the black containers/ mats are heated exclusively by solar radiation. The pool water must be pumped through the mats/collectors with the filter system, which is then heated there.

The pool is not heated, what can I do?

Check that all connections are correctly connected. Switch on the filter system. Use the maximum possible solar radiation and increase the running time of the filter pump. Cover the pool overnight to prevent heat loss.

Should I use a bypass?

In many solar systems, the diameter for the water flow is reduced and with it the entire circulation capacity of the existing filter system. To eliminate this potential problem in advance, we recommend using a bypass set. This not only regulates the heating output, but also specifically controls the water flow.

Symbol photos

The pictures shown are just for reference, the actual product may differ.
